AMD X670E Extreme Chipset, 20Gbps USB-C and Gigabyte Aorus Gen5 AIC

Описание: We're Going to cover 3 Technologies with this Video today. 1. AMD Chipset X670 Extreme. 2. 20Gbps USB-C 2x2. 3. Gigabyte Aorus Gen5 AIC which is a X16 Card that requires 4x4x4x4, 16 Lanes, fully Bifurcated. Of the 4 Requirements... 1. PCIe 5.0. 2; A X16 PCIe Slot; 3. Full Motherboard Bios Bifurcation of 4x4x4x4; 4. Requires 4 M.2 NVMe PCIe 5.0 Drives. 1st Generation of those will be 10,000MBps per Drive. The Spec for PCIe 5.0 NVMe can take that to 15,000MBps per Drive. Expect to see 3 Generations of NVMe Drives just as We had on PCIe 4.0. We'll be looking at the Phison E26 Controller when the times comes with Micron Memory. Of the 5 Motherboard Manufacturers, We're going to show 2 for an Overview and Implementation of PCIe 5.0 with Slots and Storage and what it takes to utilize the Aorus Gen5 AIC. We'll cover USB-C DisplayPort Alternate mode and Thunderbolt / USB4 PCIe Tunneling over USB4.

X670E Design vs Implementation - Consumer Desktop Motherboard
Faster CPU
Faster Chipset
Faster RAM
CPU Core count remains the same.
PCIe Lane count remains same.

Slots and Storage

USB-C can support 3 Technologies...
1. Data
2. USB Power Delivery
3. DP Alt Mode - DisplayPort Alternate-Mode

10Gbps USB-C - DP ALT Mode
20Gbps USB-C 2x2
40Gbps Thunderbolt 4 or USB4 - PCIe Tunneling over USB4
Thunderbolt 4 (Intel Maple Ridge JHL8540) or USB4 (ASMedia ASM4242).

Question: Lane count. Does a Device use 2 Lanes or 4 Lanes. Built on vs Add in card. Depends!
