ANENG AN-CM82 rewind ,AC + DC clamp meter.made in china.

Описание: ANENG AN-CM82
CATIII600V,6000 COUNTS
AC/DC 600A ,LCD SCREEN
AUTO RANGING clamp meter

(AC/DC VOLTAGE/CURRENT
DUAL IMPEDANCE VOLTAGE
STARTING INRUSH current
NCV,CONTINUITY
TRUERMS,FLASHLIGHT
BACKLIGHT,RESISTANCE
CAPACITANCE,LED
FREQUENCY,TEMPERATURE
HOLD,APO)

size 185x65x30mm
weight 165g
battery AAA x1.5vx2pcs
TEST pen CATIII600V,10A
pvc CABLE 64CM long,
4mm plug
jaw mouth max 25mm
DCV 0.001V TO 600V
(±0.5%+3)
ACV 0.001V TO 600V
(±1%+3)
DCA 0.01A TO 600A
(±2%+10)
ACA 0.01A TO 600A
(±2%+10)
RESISTOR 0.1 TO 60M OHM
(±1.5%+3 ) (±0.5%+3)
CAPACITOR 0.001nF to 60MF
(±5%+20)(±2%+5)(±5%+5)
FREQUENCY 0.01HZ to 300khz
(±0.1%+3)


(in this list of data may be
have an error because it
only for Mark from the eye
please notice.)😂


main ic no name
48PIN no name
14pin GS8334
CE16CA
PTC R33 3BDMZ 1.064K
PTC R17 3BDMZ 1.064K
CRYSTAL 8.000
BUZZER SHORE LINEELEC
R5 GRN,BLK,BLK,
YEL,BLU
R6 GRN,BLK,BLK,
YEL,BLU
=5M OHME
R8 BRN,BLK,BLK
YEL,BLU
= 1 M OHME
R4 BLU,BLK,BLK.ORG,
GRN=600k ohm

NTC1 27.45k ohm
Q1 Y2
Q2 Y1
Q3 Y1
Q4 Y1
Q5 Y2
R1 01C
R3 101

R7 470
R10 01D
R11 01C
R12 470
R13 01C
R15 106
R16 01B
R18 10C
R19 10C
R9 472
R20 623
R21 433
R22 18C
R23 473
R24 30B
R25 01C
R26 01C
R27 01C
R28 01C
R29 01C
R30 01C
R31 01C
R32 01C
R34 01C
R35 01C
R36 01D

※※remark that
1.) this meter max mouth
jaw is 25mm .
2.)this meter the upper
small display the FREQUENCY is
2.8khz at AC 6V sin wave
3.)this meter the LOWER
display max is 148khz
at AC 6V sin wave .


Thx for watching.
