Vectorworks Tutorial Basic 11: site model creation, property line, solar shadow;
Автор: {Yang Song}
Загружено: 2018-12-31
Просмотров: 10798
Описание:
VECTORWORKS Playlist: • Vectorworks Tutorial Basic 1: setting up, ...
-Flyover tool mode issue; use layer plane origin mode;
-Create a site model using 3d polygons;(make sure you convert cad lines to 3d polygons)
-Use the reshape tool to reshape site model to a rectangle;
-Use clip tool to clip site contour;
-Change site model graphics; Save graphic styles;
-Create a property line and set up units.
-Use the rotate plan tool to rotate the drawing for better drafting;
-Create massing models and send massing models to the surface;
-Create shading using heliodon tool; (make sure it is in OpenGL mode and OpenGL shadow setting is checked)
