Simcenter Femap 2022.1 — Solution Monitor

Описание: Simcenter Femap 2022.1 supports direct access to the Simcenter Nastran Solution Monitor, allowing you to view the results of an analysis and/or review curated output from Simcenter Nastran. This includes information, warning, and error messages recovered directly from Simcenter Nastran while an analysis is running or after upon completion.

Solution Monitor is most helpful when used to monitor Simcenter Nastran Multistep Structural and Multistep Nonlinear Kinematic Solutions Sequences, SOL 401 and SOL 402, which are the default for such analyses. The Solution Monitor can also be used for other types of analysis by selecting the appropriate option for Solution Monitor when specifying Executive and Solution Options in the Analysis Set Manager.

Solution Monitor provides immense value when using SOL 401 or SOL 402 because it provides vital information, such as the time increment and iterations for each step, convergence criteria, cumulative number of iterations, energy evolution, contact/material status, number of nodes in contact, damaged elements, creep elements, and elements which have experienced plastic deformation. Knowing this information during a multi-step solve can be used to determine if a solution is properly converging and should be allowed to continue, or if it is diverging and various options or model setup choices should be reevaluated.
