WAŚ W185 Euro Spec Universal Multifunctional Rear LED Tail Lamp

Описание: Video shows both the W184 & W185 Models

The new series of W185DD LED multifunctional rear lamps with dynamic direction indicator have an innovative design and a unique look. Each LED light: tail, cascading direction indicator and reverse, are made of a non-transparent material. This diffuses the light so individual LEDs cannot be seen, creating a pleasant glow with a neon effect. The lens and lamp housing are made of high quality plastic, which is resistant to scratches, temperature changes and UV radiation. The lamp is E-type approved and has electromagnetic compatibility approvals as well. It is easy to mount on the vehicle.

Power Consumption:
position light: 1,3W (12V) or 2,5W (24V)
side position light: 0,3W (12V) or 0,6W (24V)
stop light: 1,3W (12V) or 1,3W (24V)
direction indicator light: 10,8W (12V) or 10,8W (24V)
reversing light: 4,5W (12V) or 4,5W (24V)
fog light: 1,6W (12V) or 1,6W (24V)
bottom numerplate light: 0,4W (12V) or 0,8W (24V)
side numberplate light: 0,8W (12V) or 1,5W (24V)

Weight Lamp: 1,3kg
Cable Length: 2m
IP class: IP 66/68
Approval: E20, R10, R23, R7, R

Wiring Instructions:
1. White – ground, negative
2. Black – tail, rear position
3. Yellow – indicator
4. Grey/brown – reversing
5. Blue – fog
6. Red - brake

Available for Purchase Exclusively at www.BlingLights.com
Contact [email protected] With Any Questions
