Standing Wave Pattern Animation (SWR)
Автор: meyavuz
Загружено: 2010-04-01
Просмотров: 57687
Описание:
Uniform plane wave traveling in the +z direction and normally incident on a medium interface at z=0. Only the electric field intensity is shown.
The top figure shows the incident (blue), reflected (red), incident+reflected (brown) and transmitted field in both media. In the bottom figure, the standing wave patterns created in both media are shown.
For medium with nonzero conductivity, check the following animation: • Standing Wave Pattern (SWR) and Propagatio...
Stehende Welle, Onda estacionaria, Onde stationnaire, Staande golf, Onda estacionária, Стоячая волна, 駐波, 定常波, 정상파, Undă staționară, Торгын дулкын, Fala stojąca, Seisova aalto, Stående våg, موجة راكدة, Στάσιμο κύμα, , Onda stazionaria, גל עומד, Állóhullám , Тұрғын толқын, คลื่นนิ่ง, Stovinčioji banga, Stāvvilnis, Stojni val, მდგარი ტალღა, Ona estacionària, Ton sefyll, Seisulaine
