Different Type of Stirrups in Beam and Column | What are One-Leg Two-Legged Stirrups By CivilGuruji

Описание: Different Type of Stirrups in Beam and Column | What are One-Leg Two-Legged Stirrups

Start Your COPs Training NOW
Join this Training and get started:- https://civilguruji.com/s/store/cours...

For More Details Call Now : 9111001234

What are Type of Stirrups 00:00
One Legged Stirrups 01:15
Two Legged Stirrups 01:29
Three Legged Stirrups 02:14
Four Legged Stirrups 02:48
Importat Information 03:10
Five Legged Stirrups 05:10
Six Legged Stirrups 06:00
Seven Legged Stirrups 07:25
Eight Legged Stirrups 07:57
Full Information of Multi Legged Stirrups 08:33

About This Video -------------------------------------------------------------------------------
In this video Er. Sudeep Kumar Agrawal, Corporate Trainer of Civil Guruji, is Explaining About Different Type of Stirrups in Beam and Column | What are One-Leg Two-Legged Stirrups

Different types of Stirrups are used in the construction industry such as Single Legged Stirrup, Two-Legged Stirrup, Three-legged Stirrup, etc.

Stirrups are rectangular steel pieces used to resist lateral shear stress and diagonal tension stress in RCC structures. Stirrups help to hold in place the primary reinforcement bars and prevent buckling failure in columns. Different Type of Stirrups in Beam and Column | What are One-Leg Two-Legged Stirrups

Single Legged Stirrup:
This type of stirrup is very rarely used. It can be used to bind two reinforcement bars. Single Legged Stirrup is not used in beam and column because there are more than 2 bars to tie. Different Type of Stirrups in Beam and Column | What are One-Leg Two-Legged Stirrups

Two Legged Stirrup:
The two-legged stirrup is the most popular type of stirrup in the construction industry. As you can see n the figure, 4 reinforcement bars are required to bind together. Different Type of Stirrups in Beam and Column | What are One-Leg Two-Legged Stirrups

If you visit any construction site, you can observe mostly these types of stirrups are used.

Three-legged Stirrup:
As you can observe from the figure, in this arrangement a two-legged stirrup and single-legged stirrup are used to tie 6 reinforcement bars.

Four Legged Stirrup:
A four-legged stirrup generally consists of two overlapping stirrups that don’t wrap all the rods.

When we use a single stirrup to tide a beam or column at the same time, we are saying it is a two-leg stirrup and thus if we use a Double stirrup to tide than a beam or column at that time, we say it is 4 leg stirrups. that’s why A single stirrup has two legs.

Five Legged Stirrup:
It is the combination of a four-legged stirrup and a single-legged stirrup.

Six Legged Stirrup:
This very interesting type of stirrup for a civil engineer. In this, a single stirrup encircles all 8 rods and an extra leg provides additionals support. Extra legs are provided within the big stirrup which holds all reinforcement bars.

Different Type of Stirrups in Beam and Column | What are One-Leg Two-Legged Stirrups What are One-Legged,Two-Legged,Four-Legged,Six-Legged,Eight-Legged Stirrups in Construction Site,stirrups,types of stirrups in construction,cutting length of stirrups,different types of stirrups in construction,types of stirrups in beam,difference between stirrups and ties,4 legged stirrups in columns,use of stirrups and ties in beam and column,stirrups in beam,stirrups in column,how to calculate cutting length of 4-legged stirrups,what are the types of stirrups
