Hager ESC225 | 25Amp 2 Pole Contactor 240V | 2 N/O
Автор: Sparky Direct
Загружено: 2021-03-28
Просмотров: 37188
Описание:
Hager ESC225 | 25Amp 2 Pole Contactor 240V | 2 N/O
Available at Sparky Direct - Electrical Online Wholesaler
https://www.sparkydirect.com.au/p/Hag...
A Contactor is an electrically controlled switch that is used to control a larger power load.
The Hager ESC225 contactor is commonly controlled by a circuit with much less current then the contactor switch circuit. It is ideal for controlling the power to electric motors and large lighting applications.
The ESC225 is a 25 Amp contactor - which is a perfect size to control the power going to a inductive load such as a pool pump, hot water system etc. Can be used in conjunction with any timer to satisfy inductive loads.
Features:
Contactor
240v
2 Pole
25amp
2 Normally open
Dimensions
Depth of installed product: 60 mm
Height of installed product: 83 mm
Width of installed product: 17,85 mm
Fluorescent bulbs control
Max. load fluorescent lamp: 950 VA
Max. power with fluorescent parallel lamps: 810 VA
Fluorescent lamps in duo circuit: 1990 VA
Incandescent bulbs control
Max. power with incandescent lamps: 1900 W
#ElectricalSupplies #SparkyDirect #Electricalwholesaler
