Simulating Drop Loads Impact on a Structure with FEMAP and NX NASTRAN - Part 2
Автор: Saratech
Загружено: 2016-06-06
Просмотров: 5450
Описание:
This 30-minute webinar is a follow up to the presentation on Jan 24 2013 (View on demand here) on modeling a mass impacting a structure and load recovery using NX NASTRAN linear transient solution. This solution worked well; however, it did not simulate true contact dynamics. In Part II, we will demonstrate how to use GAP elements to simulate a contact surface. This simulation will require NX NASTRAN Nonlinear solution to model boundary conditions at the surface of impact.
Topics that will be covered:
Type How to define impact conditions
Assessing different solutions for impact assessments
Using GAP elements to simulate contact surface
Setting up a Nonlinear solution
