Extrusion Process Defects || شرح بالعربي || مشاكل وعيوب عمليات البثق

Описание: The defects can be classified into the following
categories
1- Centerburst
This defect is an internal crack that develops as a result of tensile stresses
along the centerline of the work part during extrusion. Although tensile stresses may seem unlikely in a compression process such as extrusion, they tend to occur under conditions that cause large deformation in the regions of the work away from the central axis. The significant material movement in these outer regions stretches the material
along the center of the work. If stresses are great enough, bursting occurs. Conditions that promote centerburst are high die angles, low extrusion ratios, and impurities in the work metal that serve as starting points for crack defects. The difficult aspect of centerburst is its detection. It is an internal defect that is usually not noticeable by visual observation. Other names sometimes used for this defect include arrowhead
fracture, center cracking, and chevron cracking.
2- Piping. Piping is a defect associated with direct extrusion. It is
the formation of a sink hole in the end of the billet. The use of a dummy block whose diameter is slightly less than that of the billet helps to avoid piping. Other names given to this defect include tailpipe and fishtailing.
3- Surface cracking. This defect results from high workpart temperatures that cause cracks to develop at the surface. They often occur when extrusion speed is too high, leading to high strain rates and associated heat generation. Other factors contributing to surface cracking are high friction and surface chilling of high temperature billets in hot extrusion.
