Corroded Amiga 500 Rev 5 (w/512k ROM upgrade and S-Video out)

Описание: #corrosion #amiga #commodore

Welcome to another video in the test and try series. This time we have an Amiga 500 and Digifex Corp VIP box. The computer actually looks a bit worse inside than I was led to believe, so I cleaned it up. Also it's a Rev 5 board so it needs a modification to accept larger 512k ROMs.

0:00 Intro
19:13 Upgrading an Amiga 500 Rev 5 to support 512k ROMs
34:20 Motherboard mod for Rev 5 Amiga 500 to support 512k ROMs
36:59 Testing the Amiga and DigiFex VIP with S-Video to a Commodore 1702
