Gas Mixer IGM-MGP2 Gometrics-ENG

Описание: This video shows the range of gas mixers developed by Gometrics. The IGM gas mixer is an industrial gas mixer designed for field use. It enables fast and accurate gas mixing and dilution operations. It is a very robust instrument with high reliability and repeatability of mixtures.
Technical characteristics:
Inlet pressure up to 103 bar (310 bar option)
Independently controllable flow rate per channel
One regulated flow output with desired concentrations
Total output flow rate max. 350 slm (2500 slm optional)
Inlets: up to 4 gas cylinders
Dimensions: 273 x 232 x 433 mm (w x h x d)

Advantages:
Versatile, intuitive software
Angled touch screen
Recipe automation
Remote control from PC
Reliability and repeatability
Safety and durability

Applications:
Preparation of gas mixtures (binary, ternary)
Calibration of gas detectors and analysers
Linearity studies of gas analysers
Characterisation of gas sensors
Preparation of controlled atmospheres for analysis

The high-precision standard gas mixer MGP2 is a more sophisticated instrument, designed for laboratory use. Its dimensions are slightly larger than those of the IGM: 403 x 263 x 552 mm (w x h x d). The MGP2 allows the connection of up to 8 bottles (option 16), has a purge outlet and an automatic cleaning system.
Furthermore, it can be coupled with a device that generates wet mixtures. In addition to the applications mentioned above, the MGP2 is used in research and development.
It has a wide range of possible applications in the food, oil and gas, energy, pharmaceutical, chemical, biotechnology and other industries.

For more information on our gas mixing solutions, please see our website https://www.gometrics.net/producto/me... or contact Gometrics at [email protected].
