DC Step Up Down Auto Buck Boost Converter 8A 5 30V 1,25-30V CC CV

Описание: ​‪@Radal05‬
link pembelian :
Automatic Step Down Step Step Up DC-DC 8A Auto Buck Boost Module CC CV
https://tokopedia.link/qETtA4oecxb
Video ini sedikit menjelaskan, hal-hal penting step up down, sebelum kalian membeli

Automatic Step Down Step Step Up DC-DC 8A Auto Buck Boost Module CC CV
Merupakan module buckboost dengan kapabilitas tinggi (hingga 8A) memiliki keungguluan dangan banyaknya proteksi yang di miliki (over current, short, dll)

Specs:
Input voltage: DC5-30V
Input current: 8A (MAX) peak value 10A (within 6A for long-term work)
Static working current: 4mA (there will be errors when the working voltage is different)
Output voltage: 1.25-30V continuously adjustable
Output current: 10A (MAX) (within 5A of natural heat dissipation for a long time, please derate when using high voltage output)
Output constant current range: 0.2-10A
Working temperature: -40~+85 degrees
Working frequency: 150KHz
Conversion efficiency: typical 91% (12V to 12V5A). 93% higher
Overcurrent Protection: Yes
Short circuit protection: yes (current limiting protection)
Over-temperature protection: yes (automatically reduce the output voltage after over-temperature)
Input reverse connection protection: no, (if necessary, please connect a diode in series with the input)
Output anti-reverse irrigation: Yes, no need to add anti-reverse diode when charging.
Wiring method: terminal output, (IN is input, OUT is output)
Module size: 60mm*53mm*22mm (length, width and height)


00 :00 Radal05
00:12 DC Step Up Down Auto Buck Boost Converter
00:23 Hati-hati barang palsu
01:25 Contoh barang yang asli
