Tutorial: Installation of the ARTILUX OLD Kit with Articulated Arms for Swing Gate Automation

Описание: In this video, we guide you step-by-step through the mechanical and electronic installation of the ARTILUX OLD Kit, an external articulated arm automation system for dual-leaf swing gates. Designed for leaves up to 3 meters, it is ideal for installation on wide pillars or wall structures. Its durable design and high-performance motor make it suitable for residential and condominium settings.

Video chapters:

-Intro: 00:00
-Swing Gate Automation: Models and Considerations 00:58
-FAQ 1: Who certifies the automatic gate? 06:37
-FAQ 2: Why does the automatic gate open but not close? 07:07
-FAQ 3: Why does the automatic gate open and close by itself? 07:49
-FAQ 4: Why does the automatic gate only open from nearby? 08:36
-Automation Unboxing 09:23
-Mechanical Installation 12:37
-Electronic Installation 13:46
-Dieffematic Partner Installers 25:25

Key product features:
230V external electromechanical gearmotor with articulated arms
Surface-mounted on large pillars or walls
Suitable for leaves up to 3 meters
Max hinge-to-column distance: 35 cm
Adjustable electric limit switches
Manual release with key
Opening and closing slowdown
Independent leaf movement control
Compatible with symmetric and asymmetric gates

Kit contents:

2 articulated arm actuators 230V
1 waterproof control unit with force trimmer, slowdown, safety inputs, operation modes, and electric lock management
1 built-in single-channel radio receiver (433.9 MHz)
1 integrated antenna (20-meter range)
1 four-channel Rolling Code remote control
1 pair of wall-mounted photocells
1 flashing light
1 warning sign
Installation accessories
Manuals in Italian

Installation manuals:

Mechanical manual: cdn.shopify.com/s/files/1/0574/2601/8495/files/ARTILUXOLD.PDF
Electronic manual: cdn.shopify.com/s/files/1/0574/2601/8495/files/Euro230m2\_IT\_ECO.pdf

Product page and online purchase:
dieffematic.com/products/kit-automazione-cancello-battente-braccio-articolato-230v-220v-snodo-automatismo

For more information, visit Dieffematic:
dieffematic.com
