Vertical axis wind turbine performance comparison, Efficiency and Startability
Автор: Smart Servo
Загружено: 2023-11-30
Просмотров: 9556
Описание:
Although lift-type vertical axis wind turbines are highly efficient, they are not easy to self-start. This video uses Magnus rotors to start the wind turbine, and conducts experimental comparisons with traditional drag blades. The new method can meet both starting performance and high efficiency, with a simple structure and low cost. ...
Patent：TWI 710698B
File sharing (continuously updated)：http://smartservo.org/en/magnus-vawt-...
More info.：http://smartservo.org/en/magnus-effec...
wind turbine parameters：
Small drag blade：W 165mm，H 180mm
Large drag blade：W 185mm，H 180mm
Lift blade：NACA0015，Chord 118mm，H 400mm
Long rotor：Dia.50mm，H 200mm，Endplate Dia. 100mm
Short rotor：Dia.50mm，H 130mm，Endplate Dia. 100mm
wind turbine diameter：1.01 m。
