Sunwayfoto LS-80 / LS-75 / LS-63 Ring Lens Support with Arca Swiss Plate Collar Mount

Описание: The products are available at the Sunwayfoto Online Store:
https://sunwayfoto.com/products/ls-75...

Model: LS-80/LS-75/LS-63
Inner Diameter of lInner Ring: 80mm /75mm /63.5mm
Length: 132mm /132mm /109mm
Height: 115mm /110mm /96mm
Weight: 170g /160g /130g
Mounting Socket：1/4 - 3/8

Compatible Camera Models

LS-80：Canon DSLR (6D /6D2/ 5D3/ 5D4/ 5DS/ 5DSR /50D /60D /70D /80D /90D /R /R5 /R6 /R6II) Nikon DSLR (D600 /D700 /D750 /D800 /D850) Fujifilm XT4 with Bigger Lens.

LS-75：Canon DSLR (R /R5 /R6 /R6II /R /6D /6D2 /5D3 /5D4 /5DS /5DSR /50D /60D /70D /80D /90D) Nikon DSLR (D600 /D700 /D750 /D800 /D850) Fujifilm XT4/XT5

LS-63：NEX7 /A6000 /A6400 /A6600 /ZVE10 /A1 /A7C /A7S /A7S2 /A7S3 /A7 /A72 /A73 /A74 /A7r /A7r2 /A7r3 /A7r4 /A9 /FX3

Aero-space grade aluminum material, elaborately CNC machined with high standard hard-anodized finish, making it extremely durable. The QR plate uses Arca-swiss dovetail structure, compatible with tripods or ballheads of different brands such as Arca-Swiss /RRS /SIRUI /BENRO /FOTOPRO /MARKINS.
Easy Switching between Horiztonal and Vertical Shooting: Loosen the lock-knob and rotate the camera body to certain stop and then tighten the lock-knob to swicth the camera from horizontal to vertical position without removing the camera from ballhead.
Clean Structure: Consists of an inner ring and an outer one. The inner ring is built with a camera plate to be attached on a camera base; and the outer ring is built with Arca-swiss plate at the base (with both 1/4 and 3/8 thread sockets available), can be mounted on different tripod heads
Easy to Install: firstly attach the camera body on the lens support, then attach the lens on the camera and mount the whole set on the tripod via the Arca-swiss QR plate on the ballhead or mount on a tripod directly via the base thread socket.
Better Stability: by using a lens collar, and install the whole camera and lens kit on a tripod via its base plate making the center of gravity lies between the camera and lens, which provides better balancing and stability.
