IEEE 802.15.4 ZigBee Over-Air Transmission Using SDR | PlutoSDR & RTL-SDR

Описание: #ZigBee#IEEE802154#SDR#PlutoSDR#RTLSDR#SDRangel#WirelessCommunication#IoT#RFEngineering#OverTheAir#LowPowerWireless#SignalProcessing#SoftwareDefinedRadio#EmbeddedSystems

In this experiment, I transmit a real IEEE 802.15.4 (ZigBee) frame over the air using PlutoSDR in full-duplex mode controlled via SDRangel, and successfully receive the same signal on a different laptop using RTL-SDR.

This demo proves true over-air ZigBee communication using Software Defined Radio, without any commercial ZigBee modules. The receiving system independently captures and visualizes the signal, validating timing, frequency alignment, and modulation integrity.

🔧 Setup Used:

• PlutoSDR (TX – Full Duplex)
• SDRangel (ZigBee frame transmission)
• RTL-SDR (RX on separate laptop)
• Over-air RF link (IEEE 802.15.4)

📡 What You’ll See:

✔ Real ZigBee frame transmission
✔ Over-air RF capture on a separate system
✔ SDR-to-SDR interoperability
✔ IEEE 802.15.4 physical layer in action

This video is ideal for RF engineers, SDR enthusiasts, IoT researchers, and students interested in ZigBee, low-power wireless, and protocol-level RF experimentation.

⚠️ Educational and research-only demonstration performed in a controlled environment.
