How to Wire a QS138 Motor & Votol EM200 Controller | Step-by-Step Guide!
Автор: 3C Mini Works
Загружено: 2025-02-15
Просмотров: 2590
Описание:
In this video, I walk you through the complete process of wiring a QS138 motor to a Votol EM200 controller. Whether you're building an electric bike, scooter, or another EV project, this guide will help you get everything connected properly.
Timecodes
0:00 - Intro
1:00 - Wiring Diagrams
1:24 - QS138 to Votol
1:40 - Sub Harness & Hall Sensor
2:18 - Unused Connectors
2:49 - Throttle & Gear
3:40 - Parking & Sport
4:06 - One Line & Reverse
4:40 - Hi Brake & Ignition
4:58 - Battery Connection
5:27 - Tail Light & Turn Signals
5:46 - Unused Connectors
5:58 - Relay and Converter
7:00 - DKD Speedometer
7:31 - Hand Controls
8:14 - Ignition
8:58 - Conclusion
📢 Got questions? Drop a comment below, and I’ll do my best to help! Don’t forget to LIKE & SUBSCRIBE for more Grom and EV conversion content!
#QS138 #VotolEM200 #ElectricMotor #EVConversion #DIYElectric #ElectricGrom #HondaGrom
