DAFM synth ARCADE YM2151 DIY KIT - MENU 6/6

Описание: Link in Tindie Shop:
ARCADE DIY Kit: https://www.tindie.com/products/23642/
ARCADE Assembled: https://www.tindie.com/products/21668/

GENESIS Assembled: https://www.tindie.com/products/13274/​
GENESIS DIY Kit: https://www.tindie.com/products/17166/

DAFM Synth is a FM multitimbral synthesizer series based on mythical YAMAHA chips used during 80s and 90s for home consoles, arcades and PCs sound.

The model ARCADE uses the YM2151 Yamaha chip that was used in almost all the arcade machines in those years.

Now the DAFM synth ARCADE YM2151 has been redesigned as a DIY friendly kit. This is a nice project that comprises soldering of through-hole components

This synthesizer is the perfect mix for lovers of retro video games, and makers who want to introduce themselves in the musical experimentation.

Includes presets from iconic arcade videogames like Street Fighter 2; Space Harrier; Ghouls'n Ghosts; Final Fight; OutRun; R-Type, Shinobi; Double Dragon; Golden Axe; Altered Beast; Marble Madness; Forgotten Worlds; Fantasy Zone 2 DX and Ninja Spirit.

The YM2151 has eight channels with four operators per channel. The operators can interact according to eight different algorithms. Attack-Decay-Sustain-Release (ADSR) envelopes, frequencies and low frequency oscillators (LFOs) can be modified to obtain the whole range of FM sounds.

The YM2151 chip is accompanied by the YM3012 stereo chip that allows converting the digital signal into clear and clean analog sound. Having the separate DAC allows the DAFM synth ARCADE to output a louder and cleaner sound.

The synthesizer is operated through 2 rotary encoders and has a complete menu that is shown in 4 blue OLED displays. Thanks to the beautiful tactile keyboard of 12 notes you can try the different patches as they are created. There is also the possibility of changing the octave and thus test the full sound spectrum of the Yamaha chip. Once created, the presets can be saved in the RAM memory or in an SD card as DMP files that can be opened with VGM trackers like Deflemask.

The stereo sound output is 3.5 mm audio jack, has a MIDI input to connect a keyboard, sequencer or any MIDI instrument and can be powered with a USB Type B cable (5V).

VIDEO 6/6: DEMO of the preset menu
