E&E Innovation:5-Pin SPDT Relay For Switching Loads
Автор: Tc. Mohd Naim Mohd Amin
Загружено: 2026-03-15
Просмотров: 35
Описание:
Remarks: This is my full video of my stated project. Hoping that you will be enjoying my video and comment for me to improvise on my next video.Thank you for your time 😊
=================================
Project Title:
5-Pin SPDT Relay For Switching Loads(Using 2 Light Emitting Diodes/LEDs) Using 9VDC Battery
Purpose:
To understand the application of electromechanical switch in real life.
Material(s) :
Active Component(s) :
-9VDC Battery
Passive Component(s) :
-6VDC SPDT Relay
-Single Core Jumper Wire
-Donut Board
-Green LED
-Red LED
-1K Ohms Resistor
-SPDT Rocker Switch
Apparatu(s) /Tool(s):
-Soldering Iron
-Wire Stripper
-Solder Lead
-Wire Plier
-Soldering Iron Station
-ESD Mat
-Analog/Digital Multimeter
The Step(s):Please have a look at my respective video 😊
=================================
