How to Wire Two Dimmer Switches in One Electrical Box
Автор: Daniel Villa
Загружено: 2026-03-06
Просмотров: 131
Описание:
Here we'll show you how to wire up two Lutron Diva LED+ light dimmer switches in one electrical box to control two separate light circuits. Then we'll show you how to adjust the light level when the dimmer switch is at the lowest setting.
In this project we installed a new electrical box in the wall, but these instructions will work if the box is already there and has 3 cables coming into it - one for each light circuit and one for power. A voltage tester can help you figure out which is which, if you're not sure.
This is what I used (as an Amazon Associate I earn from qualifying purchases):
Dimmer Switches: https://amzn.to/3Dtgf5p
Voltage Tester: https://amzn.to/43y4JQH
Wire Strippers: https://amzn.to/4jFpCOz
Wago Connectors: https://amzn.to/4615IcL
Screwless Wall Plate: https://amzn.to/4l6CcZD
Timestamps:
00:00 - Intro
00:42 - Finding the Power Cable
00:58 - Wiring the Switches
04:42 - Dimmer Settings
05:41 - Wall Plate
