Positive Displacement Chemical Injection Pumps

Описание: Flomore Series 3500 chemical injection pumps are electric driven, positive displacement pumps utilizing C-faced motors and common gear reducers. The gear reducers are available in 15, 30, 60, and 120 strokes per minute configurations. By utilizing even further flexibility of a wide variety of plunger sizes, the Series 2500 can fill many application requirements of different flows and pressures.

The Series 3500 can have up to four, flow adjustable heads while running fluid ends.

OPTIONS: Ceramic plungers, which provide longer packing life, and a wide variety of packing are designed to meet the demands of many different chemical applications.

■ Maximum discharge pressure: 6,000 psi (414 bar) with 3/16” plunger
■ Maximum volume 139 gallons per day per head (528 liters per day) with 1/2” plunger
■ Each head is adjustable while running
■ Available simplex, duplex, triplex, or quadruplex configurations
■ Mix or match head sizes – pump the same or different chemicals
■ Available in four-stroke rates: 15, 30, 60, or 120 strokes per minute
■ Each head is independently coupled and easy to maintain in the field
■ 1 or 3 phase, TEFC or explosion-proof, 50 or 60 Hz motors available
■ Available with 3/16”, 1/4”, 3/8”, or 1/2” plunger

For more information on the 𝗙𝗹𝗼𝗺𝗼𝗿𝗲 𝗦𝗲𝗿𝗶𝗲𝘀 𝟯𝟱𝟬𝟬 𝗰𝗵𝗲𝗺𝗶𝗰𝗮𝗹 𝗶𝗻𝗷𝗲𝗰𝘁𝗶𝗼𝗻 𝗽𝘂𝗺𝗽𝘀, visit https://bit.ly/3ygpe3D
𝗘𝗺𝗮𝗶𝗹: [email protected]
𝗣𝗵𝗼𝗻𝗲: 403-253-8320
𝗪𝗲𝗯𝘀𝗶𝘁𝗲: www.zimco.ca

𝗭𝗶𝗺𝗰𝗼 𝗜𝗻𝘀𝘁𝗿𝘂𝗺𝗲𝗻𝘁𝗮𝘁𝗶𝗼𝗻 𝗜𝗻𝗰.
11141 15 Street NE
Calgary, Alberta, T3K 0Z5

00:00 Intro
00:24 Flomore 3500 Pump
01:46 Outro
