EK Quantum Magnitude Vs. Optimus - Threadripper 3 CPU Water Block

Описание: #Magnitude #waterblock #pcbuild

EK sent me their new EK Quantum Magnitude sTRX4 D-RGB - Nickel + Plexi CPU Water Block to review and I have compared it to the Optimus Threadripper 3 CPU Water Block which greatly outperformed EK's Quantum Velocity Threadripper 3 Water Block when I tested both of them side by side a year ago.

The EK Quantum Magnitude does cost substantially more than the Optimus water block, however it does give you RGB and is actually customizable with additional attachments available from EK consisting of a respectable amount of color options. Many builds do look very similar so this is an interesting way for people to have their builds stand out a bit more from the rest.

The Optimus Threadripper 3 block doesn't have this type of customization or RGB.

Realistically, if you have spent $2,000 on a Threadripper 3970X, $500 on a motherboard, hundreds more on appropriate ram, and who knows how much on water cooling, then what's a bit more for a CPU water block w/ a look you want if it holds up in the performance area. So let's dive in and see the numbers!

Chapters:
0:00 Intro
3:47 Process
6:13 Half Time
8:20 Process & Results
10:24 End

From EKWB.com

EK-Quantum Magnitude sTRX4 - Nickel + Plexi is the newest flagship CPU water block tailor-made for AMD® Ryzen™ Threadripper™ processors. The Magnitude sTRX4, which belongs to the EK-Quantum product line, is the most complex Threadripper CPU water block on the market to date. This new lineup has no intention of succeeding or replacing their Velocity sTR4 counterparts, as the Magnitude version is a rather sophisticated alternative optimized specifically for Zen 2 based AMD Threadripper CPUs.

EK-Quantum Magnitude sTRX4 - water block for Threadripper

The award-winning, signature design truly sets the Magnitude apart, with every piece being CNC-milled from a solid piece of material. The precisely machined flat coldplate is made of nickel-plated high-grade copper and the top is made of glass-like Acrylic material. The three-dimensional aluminum mounting frame perfectly blends in with the asymmetrical shape of the Threadripper CPU socket, while making the screws a seamless part of the water block. Strong edges and chamfers root this futuristic design firmly into the EK Quantum line. Magnitude proudly bears the prestigious iF Design Award.

It is possible to rotate the Insert by 180°, thus exchanging the optimal inlet and outlet ports so that the flow direction may be reversed. Because the SP3 sockets are asymmetrical, and to prevent incorrect re-assembly, it is not possible to rotate the top, frame, or coldplate relative to the socket. The accents in a different color are available separately and can easily be replaced.

Accents on the EK-Quantum Magnitude sTRX4 - Nickel + Plexi

The water block implements the evolution of the patent-pending technology called TDC, or Targeted Die Cooling. This technology was first developed for the 2nd generation EK Threadripper CPU water blocks. The Magnitude now utilizes it on a more sophisticated level. The cooling engine is enlarged significantly. The coldplate is now completely flat with the 4 patches that ensure optimal contact with the IHS over CCDs creating ideal conditions for best thermal transfer. Two 0.5mm thick jet plates make sure that coolant flow is focused and turbulent over the CCDs (Core Complex Dies).

EK-Quantum Magnitude sTRX4 - water block for Threadripper

This product is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin LED connector is to be aligned with the +5V marking on the addressable RGB header. The Nickel + Plexi version uses the same high-density LED strip with a total of 44 addressable RGB diodes as the other LED-lit Magnitude water blocks, but they illuminate inwards, unlike other solid-top variants of this water block which shine outward. The LED Strip must be inserted through the frame and the wire can exit the block on any of the corners for best cable routing.

EK D-RGB compatibility

CPU socket compatibility:
AMD Socket sTRX4 (Socket SP3r3)
AMD Socket TR4 (Socket SP3r2)
AMD Socket SP3

AMD Ryzen Threadripper

Enclosed:
EK-Quantum Magnitude sTRX4 D-RGB - Nickel + Plexi water block
TIM / thermal grease: EK-TIM Ectotherm (1g)


From Optimus Website:
The Optimus Absolute Threadripper 3+ is made for Threadripper 3's massive core count and thermal requirements, easily handling Threadripper's overclocking potential, even if you're pushing 700 watts into your CPU.

AMD Threadripper 3 combines four of their consumer CPUs for a single XL CPU with up to 64 cores. This groundbreaking CPU needs a truly next-gen cooler to match.
