Diaphragm valve basics 1 21 21 FINAL

Описание: Keywords: AP Tech, Advanced Pressure Technology, UHP, Ultra High Purity, Semiconductor, Gas Cabinet, VMB, IGS, Substrate Gas System, Diaphragm Valve, pneumatic diaphragm valve, manual diaphragm valve, valve actuator, springless valve, seat in body, polymer seat vavle, dome shaped diaphragm, nickel-cobalt alloy diaphragm, valve push rod, rebuildable diaphragm valve, positive retract diaphragm valve, open/close indicating window, LOTO, 1/4 turn diaphragm valve, lock out tag out valve, normally closed diaphragm valve, normally open diaphragm valve, high pressure diaphragm valve, high temperature diaphragm valve, rebuildable high temperature valve, dual flow mode diaphragm valve, actuation port, soft venting valve, semiconductor, chamber venting, metering diaphragm valve, constant bleed valve


This training examines AP Tech’s diaphragm valve and actuator designs. You will learn the three types of AP Tech diaphragm valve designs and their uses using animated cutaway views. The various manual and normally open and normally closed pneumatic actuator designs are reviewed in detail with animated cutaway views of open and closed cycles. Also reviewed are two specialty diaphragm valve designs and common valve options. At the end of training, the user will be able to understand how AP Tech diaphragm valves internally seal and actuate. This training should precede other valve training such as Valve Porting
