DIY Home Built Kids Electric Jeep Willys Go Kart

Описание: Inspired by the WW2 Workhorse Willys Jeep MB, We built this mini scale electric version of the same. Its about 5 feet long and 3 feet wide and can easily carry an adult and a kid. With our boys(10 and 4) on board it goes about 20mph max. Uses 2 500W electric motor, electronic speed controller, fully working headlight, indicators, tail lights, dashboard with key ignition. Runs on 2, 35Ah battery. Steering uses a rack and pinion to make it easy on the kidos..


Drive Train:

Motor : #35 11T Sprocket + 350W 24V DC electric brush x2 Connected in Parellel- eBay Search
Brake : DRUM BRAKE FOR MINI CHOPPER AND SCOOTER FRONT OR REAR 125MM SHOES - Modified to Fit the Drum came with the Wheels - eBay Search
Chain : #35 Chain-1R Chain - ebay Search
Brake Pedels : VINTAGE CLARK GO KART / CART ALUMINUM BRAKE & THROTTLE PEDALS NOS. 5 1/2" L - eBay Search - To be Modified to fit your position
Brake Cable - Ebay Search for go kart brake cables
Wheels with Tyres : Most Expensive part : https://www.gopowersports.com -
Front : https://www.gopowersports.com/145x70-...
Rear : https://www.gopowersports.com/145x70-...
Steering : 110cc Go Kart 300mm Steering Wheel 320mm Assembly Full Steel Gear Rack Pinion - eBay Search
GO KART WHEEL SPINDLE KIT 5/8 X 3.75 KINGPIN - To Mactch the ID of the Front Wheel Bearing
Steering Column : I sed a Settl bar from Locak HW Store - Home Depot.
Flange Bearing for Steering Wheel Assembly.
Chasis : 2/4 Studs - Spindle Kit Bolted Directoely to underbody Plywood Frame and Chassis

I chose Dead Axle with Sprocket on Wheel Design to Avoid Corner Drag - So two rear wheels spin independently with each Connected to a 350W Motor using a Sprocket/Chain Mechanism;
You can find most of these parts in : https://electricscooterparts.com/ ebay or amazon

Electronics and Lights
Battery : 22AH 12v AGM SLA Battery x2 - 2x Connected in Series Giving about 30 Mins Run Time - you can go for 2x 35ah - but they are darn heavy.
Speed Controller : 24V 1000W Electric Scooter Speed Controller - https://electricscooterparts.com/spee...
Throttle : Metal Hall effect Scooter foot throttle pedal - eBay Search
Fu8se Box : 10 Way Blade Fuse Box for Automotive [ATC/ATO Blade Fuses] [100 Amp][LED Indicator] [Protection Cover] [10-30V DC; 12V] Auto Marine Fuse Block - Amazon
Hadlight : Universal 3.5" 12v H3 55w - Replace Hallogen lamp with a low watt LED - eBay(seach for H3 LED)
Indicator lights : Local harbor Fright - Cheap Trailer lights - Buy the lights before cutting the hole and plan accoridngly.
Brake Lights : Local harbor Fright - Cheap Trailer lights - Buy the lights before cutting the hole and plan accoridngly.
12V Converter : Nextrox DC/DC Converter Regulator 24V Step Down To 12V 20A 240W Low Voltage Transformer Waterproof
Horn : Mini bike Horn - eBay Search
Switch : https://www.ebay.com/itm/USA-12V-19mm...
Ignition Key Switch: Ignition Switch Cylinder Lock + 2 Keys For Electric Scooter ATV Moped Kart - eBay Search
Misc Switched - Pull Switch for Headlight - local Auto Store, LED Dash Board Lights=- ebay Search


Most truck/atv/lights are 12V So used a 24-12V buck converter to power Lights and Horn


Body :
1/2 Inch Birch Marine Grade Plywood - Local Lumber store - 1 4x8 Sheet

Paint : Olive Drab from Sherwin Williams - Choode a bit darker tint from aint Pallet - I used a Satin Finish - Didnt want glossy to hode some imperfections -looks fboulos

Tool Required:
Circular Saw/Table Saw
Jig Saw
Han held Router - Just used only for the Grill - Can also use a Jig Saw
Sockets and Wrench Set
Drill Driver Set - Prefer a Corded Drill and a Cordless Driver
Screws
Nails - I had a Ryobi Cordless Brad Nailer - Saves a ton of time - Cheap and Best tool i owned.
Paint Sprayer : You can use roller or Brush - but used a cheap HomeRight C800971.A - Again a investment if you are a homeowner and love DIY. I painted my whole house inside with it (over a few months room by room :-))

Miter Saw

Please feel free to ask any question - again the whole body was a full custom build based on a Blueprint of 1942 Willys MB Jeep - Feely available for Download from Internet. Many mechanical parts needed minor modification.
I am not a mechanic and doesnt own a shop - the whole project was built on my Home Garage with minimal tools - zero welding or metal work.
