TLP250 TESTER REVIEW IN BANGLA
Автор: Nayem Electronics BD
Загружено: 2024-06-11
Просмотров: 2477
Описание:
Transistor Inverter Inverter For Air Conditionor IGBT Gate Drive Power MOS FET Gate Drive
The TOSHIBA TLP250 consists of a GaAlAs light emitting diode and a integrated photodetector. This unit is 8−lead DIP package. TLP250 is suitable for gate driving circuit of IGBT or power MOS FET. •Input threshold current: IF=5mA(max.) •Supply current (ICC): 11mA(max.) •Supply voltage (VCC): 10−35V •Output current (IO): ±1.5A (max.) •Switching time (tpLH/tpHL): 1.5μs(max.) •Isolation voltage: 2500Vrms(min.) •UL recognized: UL1577, file No.E67349 •Option (D4) type VDE approved: DIN VDE0884/06.92,certificate Maximum operating insulation voltage: 630VPKHighest permissible over voltage: 4000VPK
Circuit DiagramLink-https://drive.google.com/drive/folder...
