Wireless HDMI Monitor Project Part 3: Housing Parts and Assembling Field Monitors

Описание: We are finally ready to put together our battery powered wireless HDMI field monitors, after two previous parts of planning and building! This episode is a big one, covering a LOT of work that was required to finish building the parts we needed and then get the monitors assembled from the piles of parts and wires.

There were several very late nights of planning, shopping, building, and video editing, but here it is! This episode (and series!) ended up much longer than expected/intended, so there will be a “Part 4” where we make some mounts and accessories for the monitors as well as actually test out their usefulness.


It is listed at the end of the video, but here is a text version of the parts list for this project:

Single Receiver Field Monitor Components:
Display (DS-15607 UPerfect USB/HDMI 15.6" 2160p)
Receiver/Transmitter Set (CB3801 WHDI Rec., CB8801 Trans.)
Battery (RP-PB064 Ravpower 32000mAh USB Battery)
VESA QD Adapter (STAND-VAD2)
Wires:
HDMI Display to Receiver (4330574023 Cerrxian)
Receiver Power to Battery (B07HQL186T DZYDZR)
Display USB C to Battery (70282 UGREEN)
Battery Micro USB Extension (B015PSU5F6 CY)

Multi Receiver Field Monitor Components:
Display (DS-15608 UPerfect USB/HDMI 15.6" 1080p)
Receiver/Transmitter Set (CB3801 WHDI Rec., CB8801 Trans.)
Batteries (RP-PB064 Ravpower 32000mAh USB Battery)
HDMI Switch (B07B8QN8FM Yishen Quad HDMI Switch)
VESA QD Adapter (STAND-VAD2)
Wires:
HDMI Display to Switch (4330543201 Poyiccot)
HDMI Receivers to Switch (B07ZC5Y3K2 Senetem)
Receiver Power to Battery (B07HQL186T DZYDZR)
Display USB C to Battery (70282 UGREEN)
Switch Power to Battery (Made from Spare Parts)
Battery Micro USB Extension (B015PSU5F6 CY)

Transmitter Camera Mount Components:
Cold Shoe 1/4" Mount (B07MZJRTH4 Anwenk)
Wires:
Micro HDMI to HDMI Female (B07K21HSQX GANA)
Mini USB to USB A (B07Z56JRK9 Tivid)


Dates of filming: September 5th, 2020 (Building Single Receiver Unit)
September 10th, 2020 (Building Multi Receiver Unit)
