RF40W RF60W high speed co2 laser marking machine wood leather acrylic laser marking machine

Описание: Machine Description:
The CO2 laser marking machine adopts an infrared light band and a 10.64μm gas laser to charge the CO2 gas into the high-voltage discharge tube to generate a glow discharge, so that the gas molecules release the laser, and the laser energy is amplified to form a laser beam for processing the material. The laser beam vaporizes the surface of the object to achieve the purpose of engraving. The above is the difference between the two, but the bigger point is the lasers of both, one using a fiber laser and the other using a gas laser.

The main parts include: laser source, scan head. control card, lens. These key components are important criteria for evaluating the quality of CO2 laser marking machines.

Machine Main Features:
1.High precision and fast speed. Marking depth is controllable optionally.
2.Wide application. It can mark most non-metals.
3.No consumption and pollution.
4.The marking lines are clear, it can withstands heavy wearing.
5. Chinese and English software are optional. The software works in Windows environment and it is compatible with many file formats, for instance, PLT, PCW, DXF, BMP and others saved by CORELDRAW, AUTOCAD, PHOTOSHOP and other softwares. Meanwhile, SHX and TTF can be imported into the software directly.

Technical Parameters:
Type specification CO2 RF40W RF60W
Wave length of laser 10.6μm
Laser repetition frequency ≤25KHZ
Laser power RF40W RF60W
Marking scope 110*110 /140*140mm/210*210mm/300*300mm optional
Marking depth ≤0.3mm(adjustable according to materials)
Laser Head Scanning head
Linear Speed ≤7000mm/s
Min.Line Width 0.03mm
Min.Letter 0.2mm
Repeated accuracy ±0.01mm
Cooling ways Air cooling
Power supply AC220V/ 50Hz/2kVA
Process Material Various of nonmetal materials
Support format PLT, BMP, DXF, JPG, TIF, AI etc
Package Size 1.17 L X0.77 W X1.09 H M
Gross Weight 165KG

Industry Application:
Tobacco, food and beverages, wines, medical packing, leather, plastic, rubber, wood products, advertisement, arts and crafts, glass, printing, ornament,etc

Marking Materials:
leather, wood, textiles, plastics, acrylic, glass, crystal, stone, MDF, dual-color board, organic glass, paper, jade, agate, non-metals etc.
