Описание: 💡 Build a PRECISE ULTRASONIC METER with ARDUINO and ROTARY ENCODER! (Ultrasonic Meter HC-SR04)

Hello everyone, and welcome back to R&M LAB GH!

In this new tutorial, we are creating a unique project: the Ultrasonic Meter, a digital measuring system based on the principle of echolocation, just like bats do!

We will see how the HC-SR04 ultrasonic sensor calculates the sound wave's return time to give us the exact distance in centimeters, displayed in real-time on the LCD screen.

🎯 The Project's Unique Features

Our Ultrasonic Meter is equipped with two advanced operating modes:

Simple Meter Mode: Measures the distance in real-time with every button press, offering excellent precision and a very fast response.

Target/Verification Mode: You can set a precise distance (Target) using the Rotary Encoder. The system provides immediate feedback (Green LED = Correct Distance, Red LED = Error/Variation) to test sequential measurements without wasting time.

🛠️ Components Used in the Project

Arduino Mini (or compatible)

HC-SR04 Ultrasonic Sensor

Rotary Encoder

LCD 16x2 I2C Display

2 LEDs (Red/Green)

1 Buzzer

1 Button

Breadboard and jumper wires

⬇️ DOWNLOAD THE CODE, INTUITIVE WIRING DIAGRAM, and DOCUMENTATION

All the necessary materials to replicate the project, including the intuitive wiring diagram I prepared (perfect for beginners!) and the complete code, can be found here:
