PreonLab - Static Mixer for Highly Viscous Fluids
Автор: FIFTY2 Technology GmbH
Загружено: 2019-01-21
Просмотров: 4949
Описание:
PreonLab benefits from an implicit viscosity solver which imposes no restrictions on the timestep and, therefore, greatly improves the performance in simulating highly viscous flows.
Static mixers are well-established devices for the continuous mixing of fluid materials within pipelines and tubes. They have no moving components and utilize the energy of the flow stream for the mixing process. An important decisive factor in choosing and designing a static mixer is its capability of mixing the streams properly resulting in a sufficiently homogeneous mixture.
The video shows the simulation of a mixing process where two streams of highly viscous flows pass through 7 single mixing units. The upper-left video highlights how the mixing process develops as the fluids pass through the mixing elements. The scenario was set-up, simulated and visualized in PreonLab.
We value your opinion - Give us feedback using the comment section below!
Connect with us - Follow us on our social media channels to retrieve regularly updates on PreonLab and FIFTY2!
LinkedIn : http://bit.ly/FIFTY2linkedin
Facebook : http://bit.ly/FIFTY2facebook
