Pure sine wave ups calibration and testing. Use dsPIC30F2010.
Автор: Ifnzu Tech
Загружено: 2022-03-25
Просмотров: 9417
Описание:
Facebook: / 535215458089459
Specification:
VOLTAGE LIMITS (INVERTER MODE) :
Mains A.C. Lower Voltage Limit :110+ 5V Lower Recovery Voltage :120+ 5V
Mains A.C. Higher Voltage Limit : 275+ 5V Higher Recovery Voltage : 265+ 5V
Output Voltage in Inverter Mode : 210V+5%
VOLTAGE LIMITS (UPS MODE) :
Mains A.C. Lower Voltage Limit :180+ 5V Lower Recovery Voltage : 190+ 5V
Mains A.C. Higher Voltage Limit : 255+ 5V Higher Recovery Voltage : 245+ 5V
Output Frequency :
Main Output Frequency : Same as Input Inverter, Output Frequency : 50.0+0.3Hz
CHARGER:
DSP controlled 4 MODE SMART CHARGING with Soft Start
TECHNOLOGY :
Processor: DSP 30F2010
16X2 LCD / 16X4 LCD / 20X4 LCD
Conversion: Full H bridge
Switching: 20 Khz Modulation
Charging: Dynamic five stage charger to decrease charging time and increase battery life
PROTECTIONS:
Battery voltage
Inverter output voltage
Percentage of load
Mains voltage
Changer on/off
Solar charging /mains charging
Inverter standby on/off
UPS mode / inverter mode
Phase input output reverse : whether mains is connected to inverter output
Neutral and phase reverse : whether neutral and phase is connected reverse
Overload
Short circuit
Overload trip
Heavy load trip
Short circuit trip
