Small Solid State Tesla Coil
Автор: TefaTronix
Загружено: 2016-03-24
Просмотров: 6413
Описание:
Read the description for specs and diagrams.
Single switch solid state Tesla coil, 74HC4046+UCC37322+IRFP260 based.
Specs:
Operating frequency: ~1MHz
Power consumption/current draw: power electronics ~10A at 24V (~240W), ~7A at 12V (~80W), driver electronics max. 250mA at 12V
Audio modulation: possible either by detuning or interruption (if the external interrupter supports it)
Output voltage: approx. 10-20kV with 24V input
Driver under-voltage lockout (at ~10.5V).
Description: http://tefatronix.g6.cz/display.php?p...
FB page about electronics, HV: https://fb.me/tefatronix
