Optional but useful things to include in prototype PCBs for testing and debugging // KiCad

Описание: #pcb #prototype #kicad
There are some useful optional things we can include in our PCBs to make debugging and testing easier. In this videos, I share about 6 optional things that I wish I had included so that I did not waste time searching or testing various configurations. I share how we can incorporate these items with KiCad in any PCBs.

‣ Some links below are affiliate. I receive a small commission at no extra cost to you.

⏰ TIMESTAMPS AND RESOURCES
0:00 Intro
1:01 Modularity with logical blocks
2:00 Options with DNP, solder jumpers, 0Ω resistors
5:24 Debugging with test points, multimeter, and pogo pins
6:45 Helpers with silkscreen notes, power, polarity, project, writable area
8:25 Mounting holes with standards and sizes
9:58 LEDs for power, indication, TX/RX, power consumption
11:24 My Twitter question & Thanks to open source projects
