Understanding Oscilloscopes - Acquisition Modes
Автор: Rohde & Schwarz
Загружено: 2022-11-21
Просмотров: 5420
Описание:
This video explains the most common types of acquisition modes used in modern digital oscilloscopes as well as additional post-acquisition processing such as interpolation and averaging.
Understanding Basic Oscilloscope Operation: • Understanding Basic Oscilloscope Operation
Learn more about R&S Oscilloscopes: http://rsna.us/6059d0LTJ
Timeline:
00:00 Introduction
00:15 Suggested Viewing
00:31 Creating waveform records from sample points
01:39 Common acquisition modes
01:55 About sample mode
02:30 About peak detect mode
03:15 About high-resolution mode
04:15 High-resolution mode and bandwidth reduction
05:03 Additional processing of waveform points
05:24 About interpolation
06:06 Linear vs. sin(x)/x interpolation
06:43 About averaging
07:39 Summary
