Ansys Maxwell - Intro 6, Q3D Extractor
Автор: Circuit Analysis
Загружено: 2023-08-16
Просмотров: 7583
Описание:
3D Electromagnetic (EM) Finite Element Analysis (FEM) in Ansys Maxwell (previously Ansoft). This tutorial goes over how to use the Ansys Q3D Extractor to help automate the extraction of parasitics from our transfomer model. There include mutual (interwinding) and self (intrawinding) inductance and capacitance, as well as DC resistance. This video contains the following section:
0:00 Intro
0:15 Q3D Extractor
1:18 Analysis Setup
1:51 Excitations
2:54 Frequency Sweep
3:27 Simulate
3:47 Results
4:21 Capacitance
5:33 Inductance
6:15 Resistance
6:58 Additional Notes
8:01 Export SPICE
8:48 COMSOL Comparison
9:49 Conclusion
Maxwell Capacitance Matrix:
https://www.fastfieldsolvers.com/Pape...
https://courses.ansys.com/wp-content/...
Prerequisite:
Ansys Maxwell - Intro 4, Manual 3D Transformer Modeling
• Ansys Maxwell - Intro 4, Manual 3D Transfo...
This is part of the Ansys Maxwell series:
• Ansys Maxwell
