Introducing the IntelliSwitch. The Ultimate Solid State RC Switch from XGuard RC
Автор: Auggie Copter
Загружено: 2021-09-04
Просмотров: 2301
Описание:
Introducing the IntelliSwitch. The Ultimate Solid State RC Switch from XGuard RC
*ATTENTION**
The programming in this video is outdated. Please review the manual at the website to read about the 7 options and 7 tones instead of the 5 shown in this video.
You can find the manual here:
https://xguardrc.com/wp-content/uploa...
Timestamps:
00:37 Introduction
13:15 Panel Mount Hole Pattern
13:54 Dimensions of the mounting hole
08:45 Use of the Screw Terminal
15:05 Switch Operation
22:55 Using the Locator Buzzer
25:03 Switch Programming
Pre-Installed AWG 14 Cables compatible with your EC3 or XT60 Connectors (connector not included)
Illuminated light pipes one GREEN for when everything is OK and one RED when a critical low voltage is detected or blinking RED when below minimum recommended voltage.
Screw-Type terminal for larger gauge Wires for High-Current applications.
Double the servo output connectors adds redundancy and doubles current capacity
100 dB Buzzer as low-level battery indicator & Aircraft Locator.
Two types of Battery Chemistry
• 7.4V Lipo (2S)
• 7.2V Ni-Mh (6 cell)
• Note: (LiFe packs can also be used but it will only warn if voltage below 6.2V)
