ALZMETALL AB35 HST Pillar drill
Make : ALZMETALL Germany
Typ : AB 35 HST
Age : 1254
YOP : 1978
Max. drill Ø steel : 35
Max. drill Ø cast : 40
Max. tap Ø : M25
Stroke : 180
Troth : 330
Cast iron guide way: 210
Quill Ø : 60
Spindle taper : Mk 4
Speeds : 65 – 1.750
Feeds 3 steps : 0.06 – 0.12 – 0.18
Min. table spindle – table: 80
Max. table spindle - table : 870
Table size : 600 x 700 mm
Table load : 325 Kg
Dimensions
Length : 1.200
Width : 880
Height : 2.800
Weight : 1.000
Power : 380 V / 2.2 kW
Please Note: The above information has been obtained to the best of our ability and belief from, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
