How to SAVE a Failed CNC Plasma Cut!

Описание: Check out the CNC Table HERE: https://www.eastwood.com/eastwood-eli...

Eastwood Elite 4' x 4' CNC Plasma Cutting Machine with FREE 60 Amp Plasma Cutter
This machine is designed for the professional cutting up to 3/8” plate all day or the small fabricator cutting a variety of materials and shapes. Combine the large 4' x 4' work surface with the robust welded frame design and this unit will handle sheets up to 1000 lbs., making it great for nearly any job. Included FREE is our Inverter Powered 60 amp plasma power supply that cuts cleanly through 3/8’ steel plate with unmatched accuracy, cut quality and reliability. It’s backed by a 1-year warranty and our lifetime tech support. Now is the time to start a new hobby, business, or expand your current business with another CNC table.


The Eastwood 4' x 4' CNC Plasma Cutting Table Features:
CNC Table operates on standard 120 volt AC input
60 Amp Plasma Cutter operates on 240 volt AC input
Intuitive interface with easy to use touch screen
CNC Controller makes it easy for beginners, yet has the features a pro requires
Dedicated CNC Controller so you don't have to supply a laptop to operate the machine
Robust 3 axis stepper motors assure long life and accurate cuts
Heavy gauge welded frame design assures a rock-solid foundation
Rigid design for precise gantry movements and cutting accuracy
Long 23' torch cable on CNC Table
Steel table construction holds 60.23 Gallons
Large Waterbed: 59.05" X-Axis; 62.99 -Axis; 3.75" Z-Axis
Torch travel is 49.2" in both X-Axis and Y-Axis
Leveling feet for accurate height adjustment
Plasma Cutter has a 60% Duty Cycle at 63 Amps and 100% at 49 Amps
Includes everything to get started - all you need is a CAD file
Backed by Eastwood's 1-year warranty

Precise Metal Cutting Accuracy
This innovative, affordable, Elite CNC Plasma Cutting Machine was designed and developed by Eastwood's own R&D staff and tested in-house on the same type of real-life projects you'll be doing. The intuitive interface and touch screen controls are simple enough for a beginner yet loaded with the features the professionals need.

The quality stepper motors combined with the heavy duty frame provides the rock-solid foundation you require for the accuracy you demand. This Elite CNC Machine includes everything you need to start cutting, including a FREE 60 Amp Plasma Cutter, all you have to supply is the CAD file!

WARNING: Beware of lesser units that don't include a quality waterbed, sturdy fully welded frame construction, integrated control panel so you don't have to also purchase a laptop computer, precise torch height control or an included plasma cutting machine. Eastwood supplies all of this and more!

Warranty

1 Year Warranty
Specifications

CNC Table Specifications

Power Input: 120V, 50/60Hz, 1Ph, 1.25A
Power Plug: NEMA 5-15P
Table Construction: Steel
CNC Torch Travel: 49.2" X-Axis and Y-Axis; 2.5" Z-Axis
CNC Torch Hose and Wire Length: 23'
Waterbed Size: 59.05" X-Axis; 62.99" Y-Axis; 3.75" Z-Axis
Waterbed Size: 60.23 Gallons (228 Liters)
Movement Accuracy: ± 0.1mm
Cutting Accuracy: ± 0.5mm


60 Amp Plasma Cutter Specifications

Power Input: 240V, 50/60 Hz
Power Plug: NEMA 6-50P
Air Input: 1/4” NPT Female Thread
Output Current Adjustment: 10-63 Amps
Duty Cycle: 60% @ 63 Amps; 100% @ 49 Amps
Arc Ignition Mode: High Frequency
Plasma Torch and Hose Length: 12.3'
Ground Cable Length: 9'
Plasma Cutter Weight: 54.5 lbs
Plasma Cutter Dimensions: 10.83" x 22.44" x 18.70"
