Estimating the Power Requirement of a Rushton Turbine Using Pointwise and OpenFOAM
Автор: Applied CCM
Загружено: 2015-07-27
Просмотров: 2516
Описание:
The webinar will demonstrate how to use Pointwise to generate high-quality unstructured meshes suitable for steady-state moving reference frame calculations, using a generic, baffled tank stirred by a Rushton turbine. The boundary conditions and zones necessary for OpenFOAM will be demonstrated using Pointwise's recently-updated native interface. Also shown will be how to prepare an Open FOAM case for a moving reference frame calculation and compute the power necessary to drive the Ruston turbine in a single-phase flow.
Unstructured surface mesh on the Rushton turbine +
Rushton turbine unstructured surface mesh
Presented by Travis Carrigan and Dr. Darrin Stephens, the webinar will demonstrate how to
-Resolve thin geometric features using diagonalized quad grids
-Quickly create point-matched periodic surface meshes to ---improve interpolation accuracy
-Save time by creating Sets and Zones for OpenFOAM directly -within Pointwise
-Easily setup OpenFOAM cases for moving reference frame calculations
-Compute torque/power requirements using OpenFOAM functions
