V8 Solenoid Engine with Electronic Ignition
Автор: Joe Miller
Загружено: 2015-04-03
Просмотров: 19628
Описание:
Electric Solenoid Engine in V8 configuration.
Ignition/commutation controlled by an mbed enabled microcontroller with input from a shaft encoder that decodes the crank shaft position. The microcontroller is a Freescale KL25Z on thier FRDM-KL25Z development board with mbed interface. The unit has two modes. 1-Power control, 2-Speed Control with PID and feedforward compensation. Speed/power and mode selection input is provided by a rotary encoder with integral push button located on the front panel. The KL25Z directly drives logic-level MOSFET transistors located in a circular pattern made to look like a distributor. The power supply is located inside the base.
The code for the KL25Z can be found on my mbed page for this project:
http://developer.mbed.org/users/JoeMi...
