Returning a #4 Turnout Diverging Rail Back to Parallel With Handlaid Track And Not Using Flextrack
Автор: Handlaid Tracks and 3D Printed Trains
Загружено: 2021-05-15
Просмотров: 147
Описание: I'm slowly getting through the track build process for my Timesaver Plus Inglenook Wye Shunting Puzzle layout. But I needed to return the diverging rail or path from a #4 turnout back to parallel with the original straight path. Since a #4 turnout is a 4:1 ratio where for every 4 units of distance down the straight path, the diverging rail will move 1 unit of distance away from that original straight path. This works out to a 14 degree angle (yay math!) So I needed a 14 degree curve to bring the diverging rail back into parallel. Sketchup and my CR10 V3 3D printer had a solution!
