2017 DMG Mori NHX 4000 CNC Horizontal Machining Center

Описание: EQUIPPED WITH:

Celos ERGOline Touch Controller
15.7" x 15.7" Pallets
15,000 rpm speedMASTER Spindle
Full 4th Axis
HSK63 Taper
Through-Spindle Coolant
Overhead Hydraulics
Pallet Edge Locator
40 Tool Magazine
Chip Conveyor
Renishaw OMP60
In-Machine Measuring Touch Sensor
ChipBlaster
Tool Break Detection System
SPECIFICATIONS:

Travels:
22" (560mm) X-Axis Travel
22" (560mm) Y-Axis Travel
26" (660mm) Z-Axis Travel
3.1" - 25.2" Distance Pallet Surface to Spindle Center
2.8" - 28.7" Distance Pallet Center to Spindle Gage Plane

Pallet:
15.7" x 15.7" Pallet Working Surface
880 LBS (400kg) Pallet Loading Capacity
24.8" (630mm) Maximum Workpiece Swing Diameter
35.4" (900mm) Maximum Workpiece Height

Spindle:
15,000 rpm Maximum Spindle Speed
HSK 63 Type of Spindle Taper Hole

Rapid Traverse Rate:
2,362.2 ipm (60,000mm/min) X-Axis
2,362.2 ipm (60,000mm/min) Y-Axis
2,362.2 ipm (60,000mm/min) Z-Axis

Machine Size:
100" Machine Height from Floor
105.5" x 164.6" Footprint
18,700 lbs Mass of Machine

Machine available from Gibbs Machinery Company - Warren, MI USA
