Retractable Screen for Golf Simulator, 10'x10' - Part #1

Описание: Part #1, building a retractable screen for golf simulator. The size of the screen is 10 x 10. I'm using a motor from AV-Outlet.  The screen roller is 2"x10' EMT Conduit.

Av-Outlet
Motor, AM35-6/28-E RF 120VAC Roller Shade Motor
Remote, AC123-06
Rollease Crown and Drive Adapter for 35mm Motors and 2" Rollease Tubes - MTCRDR-35-2

HomeDepot
2"x10-' EMT Conduit from Homedepot
3/4"x5' EMT Conduit from HomeDepot
Garage Door Rear Track Hanger Kit
1/4 in. x 1 in. x 1-13/16 in. Coarse Zinc-Plated Steel U-Bolt with Nuts and Strap

Amazon
2 CSB205-16 Insert Ball Bearing 1" Bore Set Screw YA100RR from Amazon

Golf simulator impact screen. $380 plus shipping.
[email protected]
Purchased from Chip from Spectrum Golf
Poly spacer impact screen.
120" x 120" with 3 inch black strip on the sides. Also sent the Velcro to be attached to the retractable roller. The screen also has a 4 inch pocket at the bottom of the screen. This pocket is used to add weight. I used a 1 inch EMT pipe filled with sand for additional weight and then covered it with 1 inch pipe insulation to prevent impact bounce back.

Commando cloth curtains for the sides of the golf simulator.
Purchased from Brad, with Chicago canvas.

Brad, with Chicago canvas and supply had the best suggestions for how to build these curtains. I elected to go with the 3" pocket at the top rather than use 7/16 grommets and hooks. He also suggested a pocket at the bottom of the curtains that would contain a chain for weight. He even supplied the chain.

Brad Mangurten
Chicago Canvas & Supply
3719 W Lawrence Ave
Chicago, IL 60625
Phone: (773) 478-5700
Fax: (773) 588-3139
[email protected]
www.chicagocanvas.com


Thanks Boomer for your videos.
