Selec XTC562 Digital Timer / Counter : Introduction | Programming - Counter mode

Описание: Featuring a capacitive touch keypad, the XTC562 offers effortless configuration that is both intuitive and user-friendly.
Designed for versatility, it supports a wide range of counter mode On delay, Interval, Time pulse repeat.
The XTC562 ensures smooth operation with proximity switches, encoders, or potential-free contacts like limit switches.

Optimized for precision and reliability, this counter is ideal for unidirectional, bidirectional, or quadrature directional counting, making it a dependable choice for diverse applications.

Features:
6 digits dual display for Timer / Counter / Rate / Batch
Programmable input scaling
Dual set point -Unidirectional, Bi - directional, Quadrature counting modes
On Delay, Interval, Time Pulse repeat.
User Configurable relay 2 operation mode

To know about Terminal connections and programming in timer mode, check the following link:
   • Selec XTC562 Digital Timer / Counter : Int...

To know more about the product, please check the following link: https://www.selec.com/product-details...

Content of the video:
0:00 Introduction
0:19 Programming -- Counter Mode
0:35 Scale factor Mantissa
0:49 Scale factor Exponent
1:01 Resolution
1:15 Counting mode
1:28 Count direction
1:38 Relay 1 Operating Mode
2:04 Relay 2 Operating Mode
2:14 Reset Mode
2:45 Input Frequency
2:55 Rate unit
3:05 Over run/ Over run

3:15 Front Panel Reset
3:27 Factory Reset
3:43 Hardware Sensor Selection
3:58 Relay 1 count set
4:18 Relay 2 count set
4:51 Relay 1 & 2 working example - On delay
5:34 Outro
