How to Install the Fabtech/Dirt Logic 3" Lift Kit - Ram Rebel

Описание: In this video I install the 3" uniball lift kit from Fabtech. This kit utilizes their 2.5" Dirt Logic adjustable coilovers, Fabtech uniball upper control arms, and 2.5" rear shocks.

Overall this kit was super easy to install. Aside form having to cut my old shock off the truck, it was very much a turn key install.

My final measurements are as follow (taken from center of hub to fender flare edge):
Front Drivers: 24.5"
Front Pass.: 24.75"
Rear Drivers: 25"
Rear Pass.: 25.25"
Overall rake: 1/2"

As mentioned in the video, here are the important torque specs:
UCA bolts to frame: 160 ft-lbs
Uniball top bolt: 106 ft-lbs
Uniball to knuckle: 120 ft-lbs
Upper coilover bolts: 49 ft-lbs
Lower coilover bolt: 93 ft-lbs
Tie rod end: 35 ft-lbs
Sway bar end links: 56 ft-lbs

Here is the kit I installed: https://fabtechmotorsports.com/produc...

I am very happy with the way the truck looks and drives. Stay tuned I will provide a follow up video after I put some more miles on the truck.

Head over to my Instagram for more pictures of projects:
  / waterfowler_41

Thanks,

WF41
