IEC 61000-4-8 EM Test Magnetic Field Test Setup & Equipment Overview

Описание: Video guide on the Ametek (EM Test) solution for high A/m testing to IEC 61000-4-8. Rent magnetic field test equipment:
https://transientspecialists.com/coll...

This video focuses on the setup and capabilities of the EM Test MFT 100 magnetic field transformer with the MFC 1000 magnetic field coil used for high A/m testing for both the continuous and short duration testing for power frequency magnetic field tests for IEC 61000-4-8.

During the video, time is spent on the different test levels that can be achieved using documentation provided by EM Test. The two different setup configurations are also shown using a variac and transient generator, as well as a power supply.

Ametek MFC 1000.1 Magnetic Field Coil
https://transientspecialists.com/prod...

EM Test MFT 100-120 Magnetic Field Transformer
https://transientspecialists.com/prod...

Contact us directly for EMC equipment at [email protected]

▬ Contents of this video ▬▬▬▬▬▬▬▬▬▬

0:00 - Introduction & Equipment
1:17 - MFT 100 Overview
1:47 - MFT 100 Connections
2:38 - Magnetic Field Document Test Levels
3:44 - Magnetic Field Document Test Setups
5:18 - MFC 1000 Overview
6:04 - MFC 1000 Connections
7:09 - Test System Connections
8:00 - Closing Remarks
