SolidWorks Tutorial: Classical Guitar #1 Body | Step-by-Step Guide

Описание: Master the Basics of Modeling a Classical Guitar Body in SolidWorks! 🎸

In the first part of our comprehensive SolidWorks tutorial series, we guide you through modeling the main body of a classical guitar. This includes the backplate, side walls, lining blocks, neck block, tail block, and the bracing system, all essential for providing the guitar with its structure and resonance. To simplify the model, you can opt to exclude internal parts like the blocks and bracing, focusing only on the backplate and side walls.
Be sure to check out the next videos in this series, where we’ll continue to build each part of the classical guitar, culminating in a final assembly that brings all components together.
__________________________________________

🔴 Watch next:
• Modeling the 2nd part of this tutorial series, the Soundboard ➜    • SolidWorks Tutorial: Classical Guitar #2 S...

🟠 Check out these SolidWorks Tutorial Series:
• Classical Guitar tutorial series ➜    • SolidWorks Tutorial: Classical Guitar Seri...
• Colt Walker Revolver 1847 tutorial series ➜    • SolidWorks Tutorial: Colt Walker Revolver ...

🟡 Don't forget to like 👍, comment 💬, and subscribe 🔔 for more SolidWorks tutorials, tips and tricks. ➜    / @draco_solano
__________________________________________

⏱ Timestamps
0:00 Intro
0:10 Modeling the Backplate and Side Walls
5:50 Adding the Tail Block
6:59 Creating the Neck Block
9:37 Placing the Lining Blocks
25:51 Designing the Bracing
34:45 Adjusting the Lining Blocks
