Muratec MT12 CNC Lathe
Year of Manufacturer 2003, Manuals and some Tooling
Swing over bed 250 mm, Swing over cross-slide 160 mm
Maximum turning diameter 240 mm
Maximum bar diameter: Standard: 51 mm
Distance centre tot centre 950 mm
Max longitudinal travel, Z-axis 200+650 mm
Max cross travel X-axis 200 mm
Spindle cone A2-5
Dia of spindle bore Ø 51 mm
Power on the spindle 7.5 kW
Number of speeds 4500 rpm
Control Fanuc CNC, Chuck: Dia. 165 mm
2 x Tool changer
Number of tools 2 x 15 driven
15-station turret on both sides
Live tool position available on all 30 turret stations
C-axis control on both spindles
High precision spindle synchronization work transfer
Hydraulic
Sliding Ring
Bar feeder LEMCA
Weight 5500 kg Compact design - Floor area 5.0 m2
Auction Finishes 7th October 2010 3pm GMT
