Vibration Analyzer VM100 with touch screen and 9 IEPE inputs

Описание: The VM100 vibration analyzer was designed for the typical
tasks of vibration measurement in laboratories and production
facilities. Despite its large range of functions, the
main focus was on ease-of-use.
The instrument software is modular, so you only need to
pay for what you need. New functions can be added later
on.
The compact unit provides up to nine IEPE compatible
sensor channels which is an outstanding feature.
All commercially available IEPE accelerometers can be
connected. Please choose from our wide range of vibration
sensors.
In addition, some modules support measurements with
IEPE type sensors for force and pressure and with IEPE
microphones.

Application
● Condition monitoring of rotating machinery, like motors, pumps, compressors, turbines or gearboxes
● Route-based measurements at machines
● Roller bearing diagnosis
● Balancing
● Measurement of hand-transmitted and whole-body vibration
● Run up/coast down analysis; resonance finding
● Vibrations on passenger and merchant ships
● Vibration measurement at very sensitive equipment (VC/Nano)

Properties
● Large screen with touch operation for clear user guidance
● 9 independent sensor channels, e.g. for three triaxial sensors
● Measurement of vibration acceleration, velocity and displacement
● Amplitude over rotation speed graphs
● Frequency analysis (FFT) with waterfall mode; Envelope analysis
● Weighting filters for hand-arm vibration and whole-body vibration
● RMS (1 s and infinite); vibration dose value (VDV); vector sum; peak; maximum peak
● TEDS sensor detection; Measurement point identification with RFID tags
● Tachometer input for RPM measurement
● Measurements saved on μSD card, PC connection via USB
● 9-channel time history plot of up to 10 hours
● Raw-signal recording as WAV file
● Infrared temperature measurement

Key Features
• Fully touch operated, simple and intuitive design
• 9 (VM100A) or 3 (VM100B) IEPE sensor channels with TEDS support
• Simultaneous 24 bit data acquisition for high accuracy
• Bandwidth 0.4 Hz to 24 kHz
• Tacho input
• NFC detection of measurement points for route measurement and saving
• Raw signal recording
• Standard data formats (CSV, BMP, WAV); no special software required
• IP65 protection grade
