Ep: 11 - How to Dim LED Backlighting for your Cockpit | DCS

Описание: Learn how to dim your LED backlit panels with a super simple and effective method, using a $5 MOSFET Board and Arduino!
You're not going to want to miss this Episode!

4CH MOSFET: https://www.aliexpress.com/item/18936...

💵 Support Me and Get $5 off your PCBWay Order
https://pcbway.com/g/6CU8SX

0:00 - Intro
0:52 - How to Dim LED
1:40 - What is Pulse Width Modulation
2:24 - Using an Oscilloscope to Understand PWM
4:32 - anologWrite
6:15 - Calculating Brightness vs. Potentiometer Output
7:42 - Arduino mapping Brightness - Potentiometer Output
15:34 - Dimming FA-18 Panel Backlighting
16:43 - Using MOSFETs to control 12V lighting
20:35 - Wiring MOSFET to FA-18 Panel
